问题 51
What is the Security Gateway directory where an administrator can find vpn debug log files generated during Site-to-Site VPN troubleshooting?
The correct directory where an administrator can find vpn debug log files generated during Site-to-Site VPN troubleshooting is $FWDIR/log/. This directory contains the following files related to vpn debug:
* vpnd.elg: This file contains the high-level VPN debug information, such as the VPN tunnel establishment, deletion, and negotiation messages. It can be enabled by using the vpn debug on command on the Security Gateway CLI.
* legacy_ike.elg: This file contains the low-level IKE debug information for IKEv1, such as the IKE packets, encryption, decryption, and authentication. It can be enabled by using the vpn debug ikeon command on the Security Gateway CLI.
* legacy_ikev2.xml: This file contains the low-level IKE debug information for IKEv2, such as the IKE packets, encryption, decryption, and authentication. It can be enabled by using the vpn debug ikev2on command on the Security Gateway CLI.
These files can be viewed by using the vpn debug view command on the Security Gateway CLI, or by using the IKEView tool on the Security Management Server GUI.
参考资料
* vpn debug – Check Point Software
* IKE Debug on R81 and above – Check Point CheckMates
* (CCTE) – Check Point Software
问题 54
Which of the following inputs is suitable for debugging HTTPS inspection issues?
The input that is suitable for debugging HTTPS inspection issues is fw debug tls on TDERROR_ALL_ALL=5. This input will enable the TLS debug mode and set the debug level to 5, which is the highest level of verbosity. The fw debug command is used to control the debug features of the firewall modules, such as TLS, CPTLS, HTTP, etc. The tls option will enable the debug mode for the TLS module, which is responsible for handling the HTTPS inspection feature. The TDERROR_ALL_ALL environment variable will set the debug level to 5, which will generate the most detailed and comprehensive debug output. The debug output will be written to the $FWDIR/log/tls.elg file, which can be collected and analyzed with the TLSView tool1 to see the details of the HTTPS inspection process, such as certificate validation, SSL/TLS negotiation, encryption/decryption, etc. The other options are incorrect because:
fw ctl debug -m fw + conn drop cptls will enable the kernel debug mode for the firewall module, with the flags conn, drop, and cptls. The kernel debug mode will generate the kdebug.txt file in the $FWDIR/log directory, which contains information about the firewall traffic processing in the kernel. The kernel debug mode is useful for troubleshooting issues related to policy, NAT, routing, and inspection, but not for issues related to HTTPS inspection, which is handled by the TLS module in the user space2.
vpn debug cptls on will enable the IKE debug mode for the CPTLS module, which is a component of the VPN module. The IKE debug mode will generate the ike.elg and ikev2.xmll files in the $FWDIR/log directory, which contain information about the IKE negotiation, authentication, and key exchange between the VPN peers. The CPTLS module is responsible for handling the SSL/TLS encryption/decryption for the VPN traffic, but not for the HTTPS inspection traffic3.
fw diag debug tls enable is not a valid command and will not enable the TLS debug mode. The fw diag command is used to control the diagnostic features of the firewall, such as packet capture, core dump, etc. The debug option is not a valid option for the fw diag command, and the tls option is not a valid option for the debug option. Reference:
How to use the TLSView tool
How to debug the Firewall kernel (fw) module
How to debug VPN issues on Quantum Spark (SMB) Appliances
[fw diag – Check Point CLI Reference Card]
问题 56
When viewing data for CPMI objects in the Postgres database, what table column should be selected to query for the object instance?
The CpmiHostCkp table in the Postgres database contains the data for CPMI objects, such as gateways, clusters, and servers. The table column that should be selected to query for the object instance is the objid column, which is the primary key of the table and uniquely identifies each object. The objid column can be used to join with other tables that reference CPMI objects, such as CpmiClusterMember, CpmiCluster, and CpmiServer. The objid column can also be used to retrieve the object name, IP address, type, and other attributes from the CpmiHostCkp table itself. References:
* Check Point Database Tool (GuiDBedit Tool) – Section: How to use the Check Point Database Tool (GuiDBedit Tool) – Subsection: How to view the data in the database
* Check Point Certified Troubleshooting Expert (CCTE) – Exam Topics – Module 6: Advanced Management Server Troubleshooting
* [Check Point R81 Database Schema] – Section: CPMI Tables – Subsection: CpmiHostCkp Table
问题 60
You run cpwd_admin list on a Security Gateway and notice that the CPM process is not listed. Select the best answer.
The cpwd_admin list command is used to display the status of processes monitored by the Check Point WatchDog Daemon (CPWD). The CPM (Check Point Management) process is a core process on the Security Management Server, responsible for management operations. However, on a Security Gateway, the CPM process is not typically present, as it is specific to management functions.
Option A: Correct. The output of cpwd_admin list differs between a Security Gateway and a Security Management Server. On a Security Gateway, processes like FWD, VPND, and PEP are monitored, but CPM is not present because it runs on the Management Server. Thus, CPM will not appear in the cpwd_admin list output on a Gateway.
Option B: Incorrect. While it’s true that CPM is not running on the Security Gateway, the reason it’s not listed is not because it “can’t be monitored” by CPWD. On a Management Server, CPM is indeed monitored by CPWD, but this question pertains to a Gateway.
Option C: Incorrect. CPM is automatically monitored by CPWD on systems where it runs (e.g., Management Server). There is no need to manually add it to WatchDog’s monitoring list.
Option D: Incorrect. CPM does not have its own separate monitoring system. On a Management Server, CPM is monitored by CPWD like other critical processes. The statement about “only lower processes” being monitored is inaccurate.
参考资料
The Check Point R81.20 Gaia Administration Guide explains the role of CPWD and the processes it monitors on different Check Point systems (Gateway vs. Management Server). The CCTE R81.20 course (as per and) emphasizes understanding the differences in process monitoring between Gateways and Management Servers, including the use of cpwd_admin commands for troubleshooting.https://edu.arrow.com/uk/training/course-detail/90175/Check-Point-Certified-Troubleshooting-Expert-%28CCTE%29-R81.20-%28includes-180-days%27-lab-access%29/False Reference:
The Check Point R81.20 Gaia Administration Guide explains the role of CPWD and the processes it monitors on different Check Point systems (Gateway vs. Management Server). The CCTE R81.20 course (as per and) emphasizes understanding the differences in process monitoring between Gateways and Management Servers, including the use of cpwd_admin commands for troubleshooting.https://edu.arrow.com/uk/training/course-detail/90175/Check-Point-Certified-Troubleshooting-Expert-%28CCTE%29-R81.20-%28includes-180-days%27-lab-access%29/False
https://www.koenig-solutions.com/ccte-r81-20-language-course
For precise details, refer to:
Check Point R81.20 Gaia Administration Guide, section on “CPWD and Process Monitoring” (available via Check Point Support Center).
CCTE R81.20 Courseware, which covers advanced troubleshooting of Security Gateway and Management Server processes (available through authorized training partners).
问题 69
The Check Point Watch Daemon (CPWD) monitors critical Check Point processes, terminating them or restarting them as needed to maintain consistent, stable operating conditions. When checking the status/output of CPWD you are able to see some columns like APP, PID, STAT, START, etc. What is the column “STAT” used for?
The STAT column in the output of the cpwd_admin list command shows the status of the monitored process.
The possible values are E for established, meaning that the process is running, or T for terminated, meaning that the process is not running. The STAT column is useful for quickly checking if any critical process has crashed or failed to start. If the value is T, the process should be restarted and the reason for the termination should be investigated. The STAT column does not show the Watch Dog name, the number of times the process was started, or the monitoring method of the Watch Dog.
